CFD28WIB9 07 – CABINET

CFD28WIB9 07 – CABINET

Written by

in

CFD28WIB9 07 – CABINET

Products

PositionProduct
NI241969001 Frigidaire Refrigerator Cap
NI5304521649 Frigidaire Refrigerator Wiring Harness
NI242119001 Frigidaire Refrigerator Wiring Harness
NI240494001 Frigidaire Refrigerator Plug Button
NIWCI 242118001
NIWCI 241953904
NI242072501 Frigidaire Refrigerator Insulation
NI242004802 Frigidaire Refrigerator Foam Strip
NIWCI 242061602
1AWCI 242052101
1241859701 Frigidaire Refrigerator Fan Cover
55308000010 Frigidaire Refrigerator Evaporator Fan Blade
8215474201 Frigidaire Refrigerator Washer
9241518301 Frigidaire Refrigerator Bushing
10A241860105 Frigidaire Refrigerator Gasket-Coil Cover
10A241860104 Frigidaire Refrigerator Coil Cover Gasket
10WCI 242072001
10A241860402 Frigidaire Refrigerator Evaporator Coil Cover
115303208309 Frigidaire Refrigerator Plug Hole
12INSULATION-AIR DUCT
13MOTOR,EVAPORATOR FAN
14242060201 Frigidaire Refrigerator Switch-Light/Lamp
155304517886 Frigidaire Refrigerator Light
16B241622802 Frigidaire Refrigerator Socket-Light
16242072101 Frigidaire Refrigerator Cover
16A240590403 Frigidaire Refrigerator Light Socket
16A241969202 Frigidaire Refrigerator Wiring Harness
16B241510802 Frigidaire Refrigerator Wiring Harness
175303918479 Frigidaire Refrigerator Gasket
19242072601 Frigidaire Refrigerator Support
20242072201 Frigidaire Refrigerator Cover
21241732101 Frigidaire Refrigerator Screw
21C218252201 Frigidaire Refrigerator Screw
21A5304453707 Frigidaire Oven Screw
25241949502 Frigidaire Refrigerator Clip
30241778701 Frigidaire Refrigerator Anti-Tip Bracket
34241868301 Frigidaire Refrigerator Washer
35A241767212 Frigidaire Refrigerator Lower Hinge
35241767211 Frigidaire Refrigerator Lower Hinge
36A241868202 Frigidaire Refrigerator Spacer
36241868201 Frigidaire Refrigerator Spacer
37242161202 Frigidaire Refrigerator Trim-Cabinet Corner
38241761301 Frigidaire Upper Bracket Hinge
38A241761302 Frigidaire Refrigerator Bracket-Upper Hinge
405304504486 Frigidaire Refrigerator Right Hand Black Upper Hinge Cover
40B241862402 Frigidaire Refrigerator Upper Hinge Cover
40A5304504487 Frigidaire Refrigerator Upper Left Hand Black Hinge Cover
42240578902 Frigidaire Screw Mounting Hinge
435304499445 Frigidaire Refrigerator Roller Assembly
45241500303 Frigidaire Refrigerator Screw
50242115239 Frigidaire Refrigerator Main Power Board
54241532401 Frigidaire Refrigerator Channel
58241853202 Frigidaire Refrigerator Screw
59240442708 Frigidaire Refrigerator Screw-#10-32 X 3/4
60218362501 Frigidaire Refrigerator Screw
63216396900 Frigidaire Dryer Adjustable Leveling Foot Leg
72242054802 Frigidaire Refrigerator Grille Kickplate Black
73242075701 Frigidaire Refrigerator Cam-Lower Hinge
74WCI 242026701
81134154100 Frigidaire Screw 10-32 x 0.375 Co
89WCI 241733905
90240597220 Frigidaire Sensor
92241710601 Frigidaire Refrigerator Screw
93241835502 Frigidaire Refrigerator Black Light Switch
96241860601 Frigidaire Refrigerator Evaporator Fan Mount Shroud
100242157601 Frigidaire Refrigerator Cover
101242157801 Frigidaire Refrigerator Cover
102242157501 Frigidaire Refrigerator Cover
107241971601 Frigidaire Refrigerator Light Shield
107241971202 Frigidaire Refrigerator Light Shield
108241971801 Frigidaire Refrigerator Wiring Cover
108241679901 Frigidaire Refrigerator Screw
108WCI 242118101
108WCI 241971402
1155303918899 Frigidaire Damper Control Assembly
116241518601 Frigidaire Refrigerator Damper Seal
121241860103 Frigidaire Refrigerator Gasket-Evaporator
122241860117 Frigidaire Gasket
123242135301 Frigidaire Refrigerator Evaporator Motor Clip, Freezer
124242006903 Frigidaire Refrigerator Air Duct
125242071201 Frigidaire Refrigerator Cover
1265304515677 Frigidaire Package of 4 Screws
