CLCE500MW1 07 – CONTROL PANEL

CLCE500MW1 07 – CONTROL PANEL

Written by

in

CLCE500MW1 07 – CONTROL PANEL

Products

PositionProduct
NI134101400 Frigidaire Dryer Kit Terminal Block
15304500452 Frigidaire Dryer Control Board
3137329200 Frigidaire Wiring Harness
45304504886 Frigidaire Control Knob
6WCI 137156200
8A00537602 Frigidaire Control Board
15SWITCH, PTS CYCLE, 8 POSITION
18WCI 137431710
21WCI 137489800
22131205100 Frigidaire Screw
23WCI 137161400
295304517938 Frigidaire Wiring Harness
325304464772 Frigidaire Refrigerator Wire Tie
39137052500 Frigidaire Switch
80134402900 Frigidaire Screw
