| 1 | Back, Main |
| 3 | Mounting Bracket Conduit |
| 4 | Wire Cover |
| 5 | W10850756 Whirlpool Screw |
| 6 | Clip |
| 7 | Screen, Burner Box |
| 8 | Insulation, Back And Bottom |
| 9 | Bottom, Main |
| 11 | Retainer, Bottom Insulation |
| 12 | Retainer, Insulation (Left Side) |
| 12 | Retainer, Insulation (Right Side) |
| 13 | Screw |
| 14 | Spring, Oven Door |
| 15 | Hinge, Oven Door (Right) |
| 15 | Hinge, Oven Door (Left) |
| 16 | Spacer, Expansion |
| 17 | W11693756 Whirlpool Screw Assembly |
| 18 | Side Trim (Left) |
| 18 | Side Trim (Right) |
| 19 | Bake Element (240 Volt) |
| 19 | Bake Element (208 Volt (Opt)) |
| 20 | Screw No.10-32x1/2 |
| 21 | Trim, Bottom |
| 22 | W10856866 Whirlpool Light Socket |
| 23 | RANGE ONLY 40W 120V APPL BULB |
| 24 | Washer |
| 25 | Screw, No.10-32 x 17/32 |
| 29 | Oven Cavity |
| 30 | Frame, Front |
| 32 | Seal, Oven Door |
| 33 | Insulation, Wrap |
| 34 | Rack, Oven (2) |
| 36 | 4396923 Whirlpool Broil Pan Set Gray Porcelain |
| 37 | Support, Broil Element |
| 38 | Washer |
| 39 | Broil Element (240 Volt) |
| 39 | Broil Element (208 Volt (Opt)) |
| 40 | Vent Tube |
| 41 | Plug, Button |
| 42 | Trim-Bottom Burner Box (Lt or Rt) |
