DC24D6-A 05 – MOTOR & PUMP

Products

Position	Product
1	TOWER BASE
2	MAY 809046
3	MACERATOR BLADE
4	SPRAY ARM BOLT
5	WIRE CLAMP
6	CLAMP RING
7	MAY 808186
8	MAY 808183
9	ELBOW & TUBE
10	MAY 808184
11	PUMP GASKET
12	GASKET
13	GROMMET
14	HEATER
15	HOSE CONNECTOR
16	IMPELR HSG KIT
17	SHROUD
18	UPPER IMPELLER
19	MOTOR
20	MAY 808181
21	NUT
22	O RING
23	PUMP PLATE
24	MAY 809102
25	PUMP SEAL KIT
26	MAY 806353
27	SCREW
28	MAY 807268
29	MAY 809022
30	SCREW
31	MAY 807270
32	SEAL TOOL
33	SHIM GAUGE
34	GASKET
35	MAY 808177
36	RING
37	MAY 808179
38	MAY 808180
39	UPR SPRAY ARM
40	MAY 803367
41	WATER SHLD, FAN
