DC24D6A 06 – INNER TUB

Products

Position	Product
1	TAPPING PLATE
2	TAPPING PLATE
3	MAY 807454
4	MAY 806539
5	STRIKE SHIM
6	STRIKE
7	MAY 806890
8	MAY 809074
9	RELAY
10	MAY 809044
11	ROLLER
12	HARDWARE KIT
13	LH GUIDE
14	MAY 804630
15	MAY 807268
16	PLATE, FLOAT TUBE
17	GASKET
18	MAY 807486
19	WHITE GASKET
20	TUB&GASKET ASM
21	RH GUIDE
22	O RING
23	FLOAT ASM
24	FLOAT SWITCH
25	BOLT
26	HINGE ASM
27	SCREW
28	MAY 808705
29	GASKET
30	MAY 804672
31	SCREW
32	INLET NOZZLE
33	INLET TUBE
34	MAY 807813
35	MAY 806593
36	WIRE SHIELD
37	CLAMP
38	GROUND TERMINAL
39	MAY 808658
40	MAY 807849
41	MAY 807501
