DE21CM 08 – FRONT PANEL & DOOR ASSY (SERIES 02)

DE21CM 08 – FRONT PANEL & DOOR ASSY (SERIES 02)

Written by

in

DE21CM 08 – FRONT PANEL & DOOR ASSY (SERIES 02)

Products

Position	Product
001	SCREW & FSTNER ASSY (FT. PNL)
002	SCREW, BUSHINGS
003	MAY 212982
004	W10169313 Whirlpool Door Switch Kit
005	MAY Y304577
006	MAY Y304578
007	MAY Y304579
011	MAY Y310376
014	SLEEVE, ACCESS DOOR RUBBER
015	LABEL, LINT SCREEN INSTR.
016	MAY Y313907
017	MAY Y313908
018	CLIP, DOOR LINER
019	MAY Y313911
020	MAY Y313912
021	MAY Y313927
022	LATCH, ACCESS DOOR
024	MAY 314077
027	DOWEL PIN FOR HANDLE
