DE24CS 04 – FRONT VIEW

Products

Position	Product
001	WP62739 Whirlpool Nut
002	MAY 203188
003	ACCESS DOOR-ALMOND
004	MAY 203188M
006	SCREW & FSTNER ASSY (FT. PNL)
007	MAY 204445
008	COIN BOX-WHITE
009	COIN BOX-ALMOND
010	MAY 205423M
012	MAY 206956
013	MAY 206956L
014	MAY 206956M
015	WP90767 Whirlpool Screw
016	MAY 212276
017	213007 Whirlpool Screw #12
018	W11165684 Whirlpool Cam
019	MAY 214660
020	MAY Y303361
026	W10176519 Whirlpool Leveling Feet
027	MAY Y305191
033	DOOR
039	MAY Y310632
040	MAY Y313908
042	DOWEL PIN FOR HANDLE
043	WPY314137 Whirlpool Rubber Foot
044	MAY 910309
