DE27S6FTMA 02 – CABINET, DRUM AND BLOWER HOUSING

Products

Position	Product
*52590	FASTENER
1A	WCI 5303281153]
1	131825900 Frigidaire Dryer Rear Drum Bearing Support Cup White
2	131724301 Frigidaire Dryer Drum Bearing Bracket
3	WCI WQ435152
4	134101400 Frigidaire Dryer Kit Terminal Block
7	WCI WQ94710
8	5303931781 Frigidaire Shaft
9	SCREW
10	SCREW (3)
11	3204254 Frigidaire Baffle Assembly
12	SPINNER BSKT
13	V ANE-FRONT (2)
13A	VANE-REAR (1) (NON-ILLUSTRATED)
13B	SCREW (9) (NON-ILLUSTRATED)
14	5303281154 Frigidaire Dryer Belt (Flat Style)
15	WCI WQ504971
16	GROMM. (FT BOLT)
17	131205400 Frigidaire Screw
18	TOGGLE KIT
19	WCI WQ634401
21	134417000 Frigidaire Seal
22	WCI WQ416306
23	FAN HOUSING
24	WCI WQ606131
25	DUCT, THERMO
26	WCI WQ182901
27	WCI WQ622925
27	WCI WQ622924
27	BODY - WHEAT
27	WCI WQ622921
28	WCI WQ505564
30	WCI WQ505011
31	WCI WQ94811
32	SCREW-BOT PAN (4)
33	5303281020 Frigidaire Ball Clip
34	5303281019 Frigidaire Ball Assembly
35	WCI WQ133283
36A	SCREW
37	WCI WQ167096
38	WCI WQ403102
39	WCI WQ623021
