DE640KDD5 04 – CONSOLE AND CONTROL PARTS

Products

Position	Product
1	BACK COVER
2	RESISTOR
3	SCREW
4	WCI 5303269972
4	WCI 5300634301
5	SWITCH – START
6	WCI 08001544
7	WCI 3201220
8	WCI 3205840
8	5303015671 Frigidaire Bracket Termination Screw
9	3205821 Frigidaire Clip
9	WCI 5303269973
10	WCI 5303281079
10	PAD (2)
11	WCI 5303281080
11	SCREW (2)
12	WCI 5303212834
12	WCI 3281101
13	WCI 5303283470
13	SWITCH-SELECTOR
14	SCREW (2)
15	WCI 3205841
16	CLIP (8)
17	WCI 3205842
17	134503600 Frigidaire Dryer Belt
18	WCI 5303212849
18	131724301 Frigidaire Dryer Drum Bearing Bracket
19	SCREW-STOP
19	WCI 5308015435
20	WCI 3281073
20	WCI 3281192
21	WCI 5303281076
21	131243800 Frigidaire Screw
22	5303281085 Frigidaire Spring Idler
22	WCI 5379171000
23	KNOB-TIMER
24	WCI 5303281083
24	WCI 08015434
25	WCI 3281036
25	WCI 5303269473
26A	5303303590 Frigidaire Dryer 4.0" Cable Tie
26	WCI 3281077
26	WCI 5303270867
27	WCI 3281200
28	PANEL TOP-ALMOND
29	WCI 3201308
30	SCREW (2)
