DES100FD2 03 – DOOR PARTS

Products

PositionProduct
1WCI 5303281053
2PANEL-O.D. ALMD
3SHIELD, HEAT
4AWCI 3201205
4SPACER (2)
5PANEL-I.D. ALMD
6WCI 5303281051
75303207102 Frigidaire Door Strike
8131658800 Frigidaire Dryer Door Catch Repair Kit
9WCI 5303281049
105303937139 Frigidaire Dryer Felt Seal and Glide Kit Drum
11WCI 5308015173
12WCI 3281089
13134417000 Frigidaire Seal
145300809968 Frigidaire Dishwasher P-1 Washer
15CLIP GUIDE (4)
16CLIP
17131420300 Frigidaire Screw
18CLIP
19WCI 5303281060
20WCI 5303281059
21DOOR-SWITCH
22GASKET, DOOR
24HINGE, DOOR (2)
25SCREW (8)
27WCI 5308015210
28WCI 5308015259
29SCREW
30WCI 5308027430
31DOOR-ACCESS ALMD
325303300265 Frigidaire Oven Screw
33WCI 5303269966
34WCI 3201264
