DG18CA 11 – INLET DUCT & HEATER ASSEMBLY

DG18CA 11 – INLET DUCT & HEATER ASSEMBLY

Written by

in

DG18CA 11 – INLET DUCT & HEATER ASSEMBLY

Products

PositionProduct
001MAY 210745
002WP90767 Whirlpool Screw
003Y304596 Whirlpool Terminal Insulator Assembly
004MAY Y303362
005WP303396 Whirlpool Thermostat
006MAY 303709
007MAY Y303778
008MAY Y303856
009WPY303881 Whirlpool Clip and Insulator
010WP303896 Whirlpool High Limit Thermostat
011MAY 304124
013WPY304693 Whirlpool Wire Jumper
014WP311093 Whirlpool Washer 7
015WP112432 Whirlpool Nut Assembly
016MAY Y312890
017MAY Y313270
