DG18CT 10 – FRONT PANEL & DOOR ASSY (SERIES 04)

DG18CT 10 – FRONT PANEL & DOOR ASSY (SERIES 04)

Written by

in

DG18CT 10 – FRONT PANEL & DOOR ASSY (SERIES 04)

Products

PositionProduct
001SCREW & FSTNER ASSY (FT. PNL)
002SCREW, BUSHINGS
003MAY 212982
007W10169313 Whirlpool Door Switch Kit
008MAY Y304577
009MAY Y304579
016306436 Whirlpool Washer Dryer Door Catch and Plastic Strike
017MAY Y310376
020SLEEVE, ACCESS DOOR RUBBER
021LABEL, LINT SCREEN INSTR.
022MAY Y313907
023MAY Y313908
026CLIP, DOOR LINER
027MAY Y313911
028MAY Y313927
029LATCH, ACCESS DOOR
031MAY 314077
034DOWEL PIN FOR HANDLE
