DG2000DW1 05 – BURNER, IGNITER AND VALVE

Products

Position	Product
1	5303281135 Frigidaire Gas Dryer Flame Sensor Radiant
2	SCREW (2)
3	134264900 Frigidaire Burner
5	WCI 08027452
6	WCI 08015296
7	WCI 08015175
8B	WCI 08027450
8A	WCI 08015489
8C	WCI 08950147
8	ORIFICE - NATURAL GAS
9	5303931775 Frigidaire Dryer Coil Kit
11	240396801 Frigidaire Refrigerator Tube Clamp
12	131243800 Frigidaire Screw
13	WCI 08015467
14	WCI 08015392
15	WCI 08027451
16	WCI 08015464
17	WCI 08015326
18	WCI 08015455
19	WCI 08002905
20	5303937186 Frigidaire Dryer Flat Igniter Assembly
22	SCREW
