| NI | WP90767 Whirlpool Screw |
| ORDER GRAPHICS PANEL FROM THE SOURCE WHERE THE DRYER WAS PURCHASED. INCLUDE THECOMPLETE MODEL AND SERIAL NUMBERS WITH ORDER. |
| 1 | MAY 52518W |
| 1 | MAY 52518H |
| 1 | MAY 52518C |
| 1 | MAY 52518A |
| 2 | MAY 51351 |
| 3 | MAY 21903 |
| 4 | MAY 51924 |
| 5 | MAY 23951 |
| 6 | MAY 54300 |
| 7 | MAY 20267 |
| 8 | MAY 03815 |
| 9 | MAY 51508 |
| 10 | MAY 51355 |
| 11 | MAY 52614 |
| 13 | MAY 22678 |
| 14 | MAY 52503A |
| 14 | MAY 52503W |
| 14 | MAY 52503H |
| 14 | MAY 52503C |
| 15 | MAY 53445 |
| 16 | MAY 23007 |
| 17 | SEE NOTE GROUND WIRE, GREEN |
| 18 | MAY 52113 |
| 19 | MAY 51350 |
| 20 | MAY 03630 |
