DG600AXD2 04 – CONSOLE AND CONTROL PARTS

DG600AXD2 04 – CONSOLE AND CONTROL PARTS

Written by

in

DG600AXD2 04 – CONSOLE AND CONTROL PARTS

Products

PositionProduct
1COVER-BACK
3131205100 Frigidaire Screw
4WCI 131062700
5WCI 131048000
6WCI 131048200
7WCI 131032900
8WCI 5303291352
93205821 Frigidaire Clip
10PUSHBUTTON (4)
11218359202 Frigidaire Refrigerator Screw
12WCI 131118600
13WCI 131048300
15WCI 5303291355
17WCI 5303291344
18WCI 5303289526
20CLIP
21131243800 Frigidaire Screw
23WCI 131118900
25WCI 131125000
26WCI 131159800
28WCI 131130304
29WCI 131062202
