DGA900F1D 04 – CONSOLE AND CONTROL PARTS

Products

Position	Product
1	WCI 3201609
2	WCI 3201349
3	WCI F139635-000
4	5303015671 Frigidaire Bracket Termination Screw
5	WCI 3201610
8	WCI F139719-000
9	WCI 3201337
10	SEMS SCREW (2)
11	WCI 01132293
12	WCI 3201615
13	WIRE-GROUND
14	WCI 0801689
15	WCI F079171-000
16A	5303303590 Frigidaire Dryer 4.0" Cable Tie
16	WCI 3201229
17	131205100 Frigidaire Screw
18	WCI F139577-000
19	WCI F139719-100
20	SCREW SWITCH TO BRACKET ( 2 )
21	WCI F060796-000
22	WCI 08001912
23	WCI F140203-000
24	WCI 08015702
25	KNOB-TIMER
26	WCI 08008462
27	SPRING CATCH
30	BRACKET-CONTROL
31	PANEL TOP-ALMOND
