| A100 | Plate Assembly,Top |
| A190 | Cover Assembly,Safety |
| A160 | EBR61144805 LG Main PCB Assembly |
| A150 | EBR79777512 LG Display Power Control Board Assembly |
| A140 | AGL75992533 LG Control Panel Assembly |
| A130 | Knob,Rotary |
| A120 | AGL74254767 LG Drawer Panel Assembly |
| A115 | Guide,Water |
| A114 | 5214EL3001E LG Pump Hose |
| A113 | MEJ54140801 LG Pump Hose |
| A112 | 4932EL3001A LG Hose Connector |
| A111 | ACZ55947005 LG Dispenser Assembly |
| A110 | EAD50732602 LG Multi Harness |
| A200 | 3210EL1003A LG Top Frame |
