DLEX5680V 3

Products

Position	Product
K560	6931EL3002M LG Dryer Thermostat
K250	4581EL2002H LG Dryer Drum Roller Assembly
K251	4581EL3001M LG Roller Assembly
K340	6500EL3001A LG Dryer Moisture Sensor
K350	6631EL3003B LG Dryer Wiring Harness
K400	3044EL0002T LG Rear Drum Tub
K410	AGB34327803 LG Dryer Steam Nozzle Assembly
K510	5835EL1002A LG Dryer Blower Fan Assembly
K515	HOUSING- BLOWER + HARDWARE
K530	5209EL1006A LG Dryer Metal Duct
K540	4975EL3001A LG Guide Assembly
K550	6323EL2001B LG Dryer Thermistor Assembly
K520	MEK37661701 LG Blower Housing
K210	3045EL1005A LG Drum Assembly
K225	MCK62973601 LG Cover Lamp
K240	5209EL1002A LG Dryer Duct Assembly
K310	5231EL1001C LG Dryer Lint Filter
K320	3550EL1005C LG Dryer Lint Filter Grille
K230	3550EL2001A LG Dryer Lamp Bulb Shield Cover
K224	4930EL3008A LG Holder
K222	6913EL3001E LG Dryer Incandescent Lamp
K600	MAZ66065301 LG Bracket Motor
K610	4681EL1008A LG Dryer Blower Drive Motor
K620	4860EL3001A LG Dryer Blower Motor Clamp
K640	EBF61734701 LG Dryer Micro Switch
K650	PULLEY ASSY-MOTOR
K651	4560EL3001A LG Dryer Idler Pulley Wheel
K655	1SZZEL3001A LG Customized Screw
F110	5301EL1001H LG Dryer Heater Element Assembly
F120	4810EL1007A LG Heater Bracket
F130	6931EL3003D LG Dryer High-Limit Thermal Fuse Thermostat
F140	THERMOSTAT ASSY
F200	5209EL1001C LG Duct Assembly
K100	3045EL1002P LG Dryer Drum Tub Assembly
K120	4432EL1002A LG Dryer Drum Baffle
K130	4400EL2001A LG Dryer Drum Drive Belt
K140	4036EL3001A LG Dryer Drum Felt Gasket
K221	6913EL3002K LG Dryer Incandescent Lamp
K330	GUIDE-FILTER
