DP4800XSG0 04 – TUB , LITERATURE AND OPTIONAL

Products

Position	Product
	WPL LIT3367225
	Paint, Spray (13 Oz.) (Platinum)
	Enamal, Toast (1 Qt. Uncut)
	Platinum (Uncut)
	WPL 72112
	350942 Whirlpool Spray Paint
	WPL LIT3367759
	285006 Whirlpool Spray
	WPL LIT3367326
	WPL LIT304287
	Leveler (Thinner) (2oz.)
	Kit, Epoxy Patch (White)
	Toast
	Golden Harvest (Uncut)
	799344 Whirlpool Refrigerator Paint
	WP72107 Whirlpool Touchup
	Almond (Uncut)
	350930 Whirlpool White Spray Paint
	350956 Whirlpool Spray Assembly
	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
	72113 Whirlpool Touch-Up Paint
	Golden Harvest
	72017 Whirlpool Appliance Touch-Up Paint White
1	WP90767 Whirlpool Screw
2	tub assembly
4	Inlet, Water
5	Hose, Inlet
6	WP596669 Whirlpool Hose Clamp
15	Nut, 7/18-16
16	Gasket
17	Nut
18	Bracket, Overflow Switch
19	Screw, 8 x 1/2 (3)
20	Gasket
21	Retainer (R.H.)
21	Retainer (L.H.)
22	Switch, Pressure (Alternate)
22	Switch, Pressure
22	Retainer-Main Top (2 Required)
26	Valve, Water Inlet
30	Nut, Twin Spring
34	Nut, Lock
35	Washer (8)
37	WP488729 Whirlpool Refrigerator Door Screw
38	Float
39	Standpipe, Overflow
40	Gasket, Overflow
41	Screw, 4-40 x 3/4
44	Shim
45	Strike
46	WP308685 Whirlpool Microwave Screw
47	Washer (8)
48	Washer, Cup
49	Roller, Rack Track
50	Screw, Shoulder (8)
51	Track (2)
52	Endcap, Front or Rear (2)
53	Screw, 8-18 x 5/8 (10)
54	Gasket, Standpipe (2)
55	Clip, Gasket (2)
56	Pad, Sound
75	Vinyl Touch Up (Blue)
75	Tine Tip Repair Kit (Blue-Enough For Two Complete Dishracks)
76	Literature Parts (Do-It-Yourself Manual 07-03 Litho In U.S.A. (bd))
76	Washer (Belt Drive)
76	Dryer
76	WPL LIT677967
