DU18D4A 04 – DOOR & ACCESS PANEL

Products

Position	Product
1	SCREW
2	LATCH ASM
3	MAY 803830
4	SWITCH COVER
5	MAY 807043
6	SCREW
7	SCREW
8	MAY 806398
9	DISPENSER
10	MAY 806757
11	BRACKET
12	MAY 807501
13	GROUND TERMINAL
14	GROMMET
15	SCREW
16	MAY 807673
17	LH ARM
18	VENT PANEL ASM
19	SCREW
20	TRIM
21	MAY 808583
22	LOCKNUT
23	ARM BRACKET
24	RH ARM
25	MAY 807534
26	MAY 803311
27	SPRING PAD
28	DOOR GUIDE
29	MAY 808749
30	SCREW
31	WIRE CLAMP
32	TRIM
33	DOOR PANEL
34	MAY 807293
35	LH DOOR TRIM
36	INSERT
37	ACCESS PNL TRIM
38	TRIM
39	TRIM
40	ACCESS PANEL
41	RH DOOR TRIM
