DU24D6A 03 – DOOR PARTS (DU24D6A)

Products

Position	Product
1	DOOR SPRING
2	RH ARM
3	MAY 803311
4	SPRING PAD
5	ARM BRACKET
6	LOCKNUT
7	SCREW
8	MAY 808749
9	DOOR GUIDE
10	INNER PANEL
11	SCREW
12	LATCH ASM
13	SWITCH COVER
14	MAY 807043
15	SCREW
16	MAY 808618
17	MAY 806398
18	RETAINER
19	OUTER PANEL
20	SCREW
21	WIRE CLAMP
22	GROUND TERMINAL
23	LH ARM
24	SCREW
25	VENT BAFFLE
26	ACCESS PANEL
27	PANEL INSERT
28	DISPENSER
29	MAY 806757
30	BI-METAL ASM
31	MAY 807673
33	GROMMET
34	SCREW
35	DOOR TRIM
36	MAY 807293
37	DOOR TRIM
38	MAY 807501
39	RH TRIM
40	BOTTOM TRIM
41	ACC PNL TRIM
42	LH TRIM
43	DOOR TRIM
44	THERMOSTAT
