DU930QWDB0 05 – DISHRACK, LIT/OPTIONAL

Products

Position	Product
	WPL LIT3374766
	WPL LIT3374754
	WPL LIT3376808
	Instructions, Installation
	Instructions, Installation (Supplement) (Locating Your Water Supply)
	Do-It Yourself Manual
	Energy Guide
1	Clip
2	Support, Arm
3	Spray Arm, Upper
4	WP3385142 Whirlpool Dishwasher Bumper
5	Tower, Pressure
6	WP3376961 Whirlpool Dishwasher Wheel
7	W10311986 Whirlpool Dishwasher Lower Rack
8	Support, Lock Spray Arm
9	Silverware Basket Assembly
10	Cover, Basket
11	Endcap, Front or Rear (2)
12	Track, Rack
13	Stop, Track (2)
14	WP3369980 Whirlpool Dishwasher Housing
15	Worm (2)
16	WP3369979 Whirlpool Dishwasher Plate
17	675791 Whirlpool Dishwasher ARM Assembly
18	W11169039 Whirlpool Dishwasher Dish Rack
19	Trim, Basket
20	Handle, Basket
21	WP9741232 Whirlpool Dishwasher Screw
22	WP3376848 Whirlpool Dishwasher Spray Arm
23	Cap, Nozzle
24	WP676455 Whirlpool Dishwasher Touch-Up
24	WP676453 Whirlpool Dishwasher Touch-Up
24	72032 Whirlpool Touch Up Paint Black
24	WP72107 Whirlpool Touchup
24	72017 Whirlpool Appliance Touch-Up Paint White
24	285006 Whirlpool Spray
24	Enamel, Black (1 Qt. Uncut)
24	350942 Whirlpool Spray Paint
24	Almond (Uncut)
24	DOOR SPRING KIT: (HEAVY DUTY)
24	350956 Whirlpool Spray Assembly
24	675679 Whirlpool Dishwasher White Tip Tines
24	Side Panel Kit: (Almond)
24	WP719576 Whirlpool Dishwasher Bearing
24	Side Panel Kit (White)
24	W10840471 Whirlpool Dishwasher Touch Up
24	676458 Whirlpool Dishwasher Tine Tip
24	Tine Tip Repair Kit (Blue – Enough For Two Complete Dishracks)
24	Avocado
24	Gold
24	Toast
24	Platinum
