ED19MTXRNR0 08 – UNIT

ED19MTXRNR0 08 – UNIT

Written by

in

ED19MTXRNR0 08 – UNIT

Products

Position	Product
1	Screw, 8-32 x 3/8
3	Condenser & Precooler
5	Clamp Tube
6	Clip (2)
7	Spring, Overload
8	case spring
9	Case, Relay
10	Box, Junction
11	Overload
12	WP488729 Whirlpool Refrigerator Door Screw
14	Relay
17	Compressor (Includes Items 43, 44, 45, 46, 47, 51, & 52) (Also Order 482801 Mounting Kit & 876765 Tu
18	876811 Whirlpool Grommet
19	303776 Whirlpool Dishwasher Screw
22	Dampener (2)
23	Exchanger, Heat
25	Clamp (4)
26	Grommet (4)
27	W11624204 Whirlpool Screw
28	Grommet, Screw
29	WP486692 Whirlpool Refrigerator Nut
30	Guard, Fan
31	Evaporator
32	Clamp
33	WP4387489 Whirlpool Refrigerator Bi-Metal Defrost Thermostat
34	WP549433 Whirlpool Refrigerator Heater
35	Wire Connector
36	Cord, Service
37	Fan, Blade
37	Fan, Blade
40	681390 Whirlpool Refrigerator Screw
42	Frame
44	833697 Whirlpool Condenser Fan Motor
45	Rail, Front
46	489340 Whirlpool Refrigerator Screw
47	Screw, 8 x 3/8
48	Bracket, Motor
49	Baffle
50	Clip, Wire (2)
51	WP2262181 Whirlpool Refrigerator Start Relay
52	Overload
53	Capacitor
54	Cover, Terminal
55	Strap
56	Screw, 1/4-28 x 1/2 (2)
57	Nut
58	Air Baffle, Evaporator
59	Washer
60	W10843121 Whirlpool Refrigerator Tube
61	WPW10662129 Whirlpool Refrigerator Run Capacitor
62	WPW10141625 Whirlpool Refrigerator Screw Assembly
63	Screw Grommet
64	Strap
65	549193 Whirlpool Refrigerator Power Clamp
66	Overload Spring
68	WPL 842041
78	Support, Evaporator
79	SCREW
81	Screw, 8-32 x 1/2
83	Clamp
94	Pan, Drip
95	Shield, Heat (2)
96	VALVE, ACCESS (1/2“)
96	876764 Whirlpool Refrigerator Primary Valve
96	978026 Whirlpool Refrigerator Primary Valve
96	Heater, Clamp (4)
96	978027 Whirlpool Refrigerator Primary Valve
96	978030 Whirlpool Refrigerator Valve
96	WP978025 Whirlpool Refrigerator Valve
96	VALVE, ACCESS (5/8“)
