EL7ATRRMQ00 04 – UNIT PARTS, OPTIONAL PARTS (NOT INCLUDED)

EL7ATRRMQ00 04 – UNIT PARTS, OPTIONAL PARTS (NOT INCLUDED)

Written by

in

EL7ATRRMQ00 04 – UNIT PARTS, OPTIONAL PARTS (NOT INCLUDED)

Products

PositionProduct
350930 Whirlpool White Spray Paint
Customer Touch-Up Material
TAPE, VINYL (3/4 X 108“)
WP505587 Whirlpool Refrigerator Sealer
WP503695 Whirlpool Refrigerator Sealer
876370 Whirlpool Refrigerator Insulation
212643 Whirlpool Refrigerator Permagum Sealer
REFINISHING MATERIAL
Miscellaneous
799344 Whirlpool Refrigerator Paint
72017 Whirlpool Appliance Touch-Up Paint White
Parts Not Illustrated and Optional Parts (Not Included)
1Cover, Evaporator
2Evaporator
3Fan Motor
4BLADE-FAN
5W11175809 Whirlpool Refrigerator Heater
6Plate, Evaporator Mount
7WP4390675 Whirlpool Refrigerator Drip Pan
84390663 Whirlpool Refrigerator Gasket
84390664 Whirlpool Refrigerator Gasket
9WP1-81801-001 Whirlpool Refrigerator Bimetallic Defrost
10Harness, Unit
112-80028-101 Whirlpool Refrigerator Motor Bracket
1260001022 Whirlpool Oven Screw
13WP3-24004-109 Whirlpool Refrigerator Screw
14Compressor (Includes Items 2, 3, 4, 5, 8 & 9)
154356716 Whirlpool Refrigerator Start Relay
16W10843121 Whirlpool Refrigerator Tube
17WP2162358 Whirlpool Refrigerator Terminal Cover
192264602 Whirlpool Refrigerator Overload
204356846 Whirlpool Refrigerator Sleeve
21Grommet, Mounting Compressor
22Washer
23Screw, Compressor Mounting
24Condenser
25WP4357245 Whirlpool Refrigerator Exchanger
26Compressor Pan (White)
26Compressor Pan (Black)
27Thermostat, Clip
28Screw
29WP3400094 Whirlpool Screw
30WP3-24838-048 Whirlpool Refrigerator Screw
323-60315-001 Whirlpool Refrigerator CAB Roller
33Axle
34Shield, Heater
35Grommet
364357128 Whirlpool Refrigerator Motor Bracket
36REFRIGERANT CHARGE 4.107 oz. (R-134A)
