| 1 | Refrigerator Door Panel (Harvest Gold) |
| 1 | Refrigerator Door Panel (Almond) |
| 1 | Refrigerator Door Panel (White) |
| 1 | Refrigerator Door Panel (Platinum) |
| 1 | Refrigerator Door Panel (Toast) |
| 2 | Cap, Hinge Sleeve (2) |
| 3 | Hole Plug (2) (Almond) |
| 3 | Hole Plug (2) (Golden Harvest) |
| 3 | Hole Plug (2) |
| 3 | Hole Plug (2) (Platinum) |
| 3 | Hole Plug (2) (Toast) |
| 4 | W10833053 Whirlpool Refrigerator Plate |
| 5 | Bracket, Door Stop |
| 6 | WP488921 Whirlpool Refrigerator Screw |
| 6 | Screw (Repair) |
| 7 | Gasket Retainer, Top & Bottom (2) |
| 8 | Retainer, Gasket Side (2) |
| 9 | Door Gasket, Magnetic (For Platinum Model Only) |
| 10 | SCREW |
| 10 | WP489069 Whirlpool Compactor Screw |
| 11 | Hole Plug (Platinum) |
| 11 | Hole Plug (Almond) |
| 11 | Hole Plug (Toast) |
| 11 | WP2212648 Whirlpool Refrigerator Hinge Sleeve Hole Plug |
| 14 | WP488920 Whirlpool Refrigerator Screw |
| 15 | Interior Door Panel (For Platinum Model Only) |
| 16 | Trim, Door Shelf |
| 17 | Compartment Door, Butter |
| 19 | Freezer Door Panel (White) |
| 19 | Freezer Door Panel (Platinum) |
| 19 | Freezer Door Panel (Toast) |
| 19 | Freezer Door Panel (Almond) |
| 19 | Freezer Door Panel (Harvest Gold) |
| 21 | Bracket, Door Stop |
| 22 | Retainer, Gaske |
| 23 | WPL 1101234 |
| 24 | WPL 1101233 |
| 25 | Trim, Door Shelf |
| 26 | Nameplate |
| 28 | Tape Strip |
| 29 | 819342 Whirlpool Refrigerator Endcap Kit |
| 31 | Handle, Center |
| 31 | Handle, Center (For Platinum Model Only) |
| 35 | Shim, Handle End |
| 36 | WP939101 Whirlpool Refrigerator Plate |
| 37 | Spa |
| 38 | WP8281206 Whirlpool Refrigerator Screw |
| 39 | WP488729 Whirlpool Refrigerator Door Screw |
| 40 | WP1101634 Whirlpool Refrigerator Cover |
| 41 | Clip, Medallion |
| 43 | Medallion |
| 46 | Screw, 6-32 x 1/2 |
| 47 | Shim, Handle |
