ET17JKXMWR0 06 – UNIT

Products

Position	Product
1	Screw, 8 x 7/8
2	Bumper, Rubber
3	condenser & precooler assembly
4	Clip, Tube
6	Spacer
8	Clamp Tube
9	WPW10141625 Whirlpool Refrigerator Screw Assembly
10	dampener
11	case spring
12	relay case
13	overload protector
14	Spring, Overload
15	Relay
16	WP717253 Whirlpool Dishwasher Connector
17	W10812038 Whirlpool Refrigerator Clip
18	Dampener
19	489340 Whirlpool Refrigerator Screw
20	Condenser Bracket (Top)
21	W11624204 Whirlpool Screw
22	Evaporator
23	4386951 Whirlpool Refrigerator Clip
24	WP487939 Whirlpool Refrigerator Nut
25	Tray, Evaporator
26	Restrictor Sleeve
27	W10843121 Whirlpool Refrigerator Tube
28	Compressor (Includes Items 32, 33, 34, 35 & 36) (Also Order 876765 Tube Kit)
29	Drier Clamp
30	Unit Mounting Plate
31	Heat Exchanger
32	Clip, Heater (2)
33	Heater, Defrost
34	Support, Heater
35	WP4387489 Whirlpool Refrigerator Bi-Metal Defrost Thermostat
36	Clamp
39	876811 Whirlpool Grommet
40	WP489069 Whirlpool Compactor Screw
41	303776 Whirlpool Dishwasher Screw
42	Pad, Sound
43	Relay
44	overload
45	Cover, Terminal
46	Cover, Spring
47	Spring, Overload
48	Unit Mounting Rail
49	978030 Whirlpool Refrigerator Valve
49	876764 Whirlpool Refrigerator Primary Valve
49	WP978025 Whirlpool Refrigerator Valve
49	978026 Whirlpool Refrigerator Primary Valve
49	VALVE, ACCESS (1/2“)
49	WP965173 Whirlpool Dishwasher Screw
49	VALVE, ACCESS (5/8“)
49	978027 Whirlpool Refrigerator Primary Valve
