ET20HDXBN00 05 – UNIT

ET20HDXBN00 05 – UNIT

Written by

in

ET20HDXBN00 05 – UNIT

Products

PositionProduct
1WP486692 Whirlpool Refrigerator Nut
2Fan, Blade
3Condenser Assembly
4WP489464 Whirlpool Refrigerator Screw
5Clip, Wire (2)
6681390 Whirlpool Refrigerator Screw
7Drain Pan/ Heat Shield
10WPW10339879 Whirlpool Wire Tie
11Strap
12Cover
13OVERLOAD
15Relay (See Overload)
16Housing Plug
17Capacitor
18Drain Fitting
19Screw Grommet
20Tube, Condenser To Heat Loop
212154109 Whirlpool Refrigerator Tube
22Evaporator
23SLEEVE
24833697 Whirlpool Condenser Fan Motor
25WPW10614158 Whirlpool Refrigerator Evaporator Tray
27W10843121 Whirlpool Refrigerator Tube
29Support, Heater
30Unit Mounting Frame
32Fan, Motor Bracket
33Heater, Defrost
34Tube, Discharge
35WP4387503 Whirlpool Refrigerator Bimetal Defrost Thermostat
38Tube, Suction
39876811 Whirlpool Grommet
40489340 Whirlpool Refrigerator Screw
41Air Baffle
42W11693756 Whirlpool Screw Assembly
43Cover-Unit Btm.
44489396 Whirlpool Refrigerator Clip
48Unit Mounting Rail
501105612 Whirlpool Fan Guard
51Drain Extension
54Support-Evaporator (L.S.)
54Support (R.S.)
70Compressor (Includes Items 71, 72, 73, 74, 75, 76, & 77) (Also Order
70876765 Whirlpool Primary Mounting Kit Refrigerator
73WP2162358 Whirlpool Refrigerator Terminal Cover
74WP2172890 Whirlpool Refrigerator Wire
75WP4387764 Whirlpool Run Capacitor
76Sleeve (4) (Service Only)
77WP4387558 Whirlpool Refrigerator Compressor Grommet
77876764 Whirlpool Refrigerator Primary Valve
77VALVE, ACCESS (1/2“)
77VALVE, ACCESS (5/8“)
77WP978025 Whirlpool Refrigerator Valve
77978030 Whirlpool Refrigerator Valve
77978026 Whirlpool Refrigerator Primary Valve
77978027 Whirlpool Refrigerator Primary Valve
