| 1 | Screw, 8 x 7/8 |
| 2 | Bumper, Rubber |
| 3 | Condenser & Precooler Assembly |
| 4 | Clip, Tube (2) |
| 5 | Clamp Tube |
| 6 | WPW10141625 Whirlpool Refrigerator Screw Assembly |
| 7 | Dampener (2) |
| 8 | Cover, Spring |
| 9 | Cover, Terminal |
| 10 | Spring, Overload |
| 11 | Overload (Used W/Original Compressor) |
| 12 | clip (4) |
| 13 | slotted washer (4) |
| 14 | Grommet (4) |
| 15 | 489340 Whirlpool Refrigerator Screw |
| 16 | W10812038 Whirlpool Refrigerator Clip |
| 17 | support grommet (2) |
| 18 | PLATE |
| 19 | Clip |
| 20 | Condenser Bracket (Top) |
| 21 | W11624204 Whirlpool Screw |
| 22 | Strap |
| 23 | Screw, 8-32 x 7/16 |
| 24 | Shim, Thermostat Plate |
| 25 | Clip, Condenser Mounting (2) |
| 26 | Restrictor Sleeve |
| 27 | Relay (Used On Service Compressor 702215) |
| 27 | Relay |
| 28 | Compressor (Also Order 482727 Installation Kit & 876527 Mounting Kit) |
| 29 | W10843121 Whirlpool Refrigerator Tube |
| 30 | Drier Clamp |
| 31 | Unit, Frame |
| 32 | Evaporator Shelves (Shelf, Bottom) |
| 32 | Evaporator Shelves (Shelf, 2nd) |
| 32 | Evaporator Shelves (Shelf, Top) |
| 32 | Evaporator Shelves (Shelf, 3rd) |
| 33 | WP488163 Whirlpool Refrigerator Screw |
| 34 | Plate, Thermostat |
| 35 | Screw, 8-32 x 1/2 |
| 36 | Heat Exchanger |
| 37 | WP308685 Whirlpool Microwave Screw |
| 38 | Box, Junction |
| 39 | Trim, Shelf Front (3) |
| 40 | 303776 Whirlpool Dishwasher Screw |
| 51 | VALVE, ACCESS (5/8``) |
| 51 | 978030 Whirlpool Refrigerator Valve |
| 51 | WP978025 Whirlpool Refrigerator Valve |
| 51 | Spacer (3) |
| 51 | Start Kit |
| 51 | VALVE, ACCESS (1/2``) |
| 51 | 978027 Whirlpool Refrigerator Primary Valve |
| 51 | 978026 Whirlpool Refrigerator Primary Valve |
