| 1 | Screw 8 - 32x3/8`` |
| 2 | panel, side l.h. (almond panel, side r.h.) |
| 3 | Left |
| 3 | Electrode (Left) |
| 3 | Electrode |
| 4 | Rear Burner-Lt. or Rt.. (Inc`s. Key 8) |
| 6 | Screw 6-20x3/8`` |
| 7 | Support-Top Burner |
| 8 | Screw 10-16x7/16`` |
| 10 | Spark Module |
| 11 | Screw 6-20x3/8`` |
| 12 | Bracket - Spark Igniter Module |
| 14 | Shut Off Valve |
| 15 | Inverted Nut 3/8`` |
| 16 | Manifold Pipe |
| 17 | Silicone Rubber Gasket (For Key 26) |
| 18 | Mounting Screw (Inc`s 86) |
| 19 | Pressure Regulator |
| 20 | Air Shutter |
| 21 | Baffle - Oven Burner |
| 22 | Screw 10 - 32 x 1/4`` |
| 23 | Igniter-Broiler & Oven Burner |
| 24 | Oven Burner Asm. (Inc`s Keys 21, 25, 26) |
| 25 | Adjustment Screw -Air Shutter |
| 26 | Air Shutter |
| 27 | Nut 6-32 |
| 28 | Bracket-Control Valve |
| 29 | Control Valve |
| 30 | Cover-Control Valve |
| 31 | Tubing 3/8`` (Shut-Off to Control Valve) |
| 32 | Switch-Gas Valve |
| 33 | Gas Valve |
| 36 | Screw 8-32 x 3/8`` |
| 37 | Clip |
| 38 | Keps Nut 8-32 |
| 39 | Front Burner-Rt. (Inc`s Key 37 & 38) |
| 40 | Adjustment Screw-Air Shutter |
| 41 | Air Shutter |
| 42 | Gas Valve (Inc`s Key 18) |
| 43 | Screw 6-32x7/8`` |
| 44 | Eyelet |
