| 1 | Screw 8 - 32x3/8`` |
| 2 | panel, side l.h. (almond panel, side r.h.) |
| 3 | Left |
| 3 | Right |
| 4 | Rear Burner-Lt. or Rt.. (Inc`s. Key 8) |
| 5 | Front Burner-Rt. (Inc`s Key 37 & 38) |
| 6 | Screw |
| 7 | Support-Top Burner |
| 8 | Air Shutter |
| 9 | Pressure Regulator |
| 10 | Screw 10-16x7/16`` |
| 11 | Mounting Screw (Inc`s 86) |
| 12 | 18850A Models |
| 13 | Inverted Nut 3/8`` |
| 14 | Shut Off Valve |
| 15 | Silicone Rubber Gasket |
| 16 | Manifold Pipe |
| 17 | Gas Valve |
| 18 | Gas Valve (Inc`s Key 18) |
| 19 | Switch-Gas Valve |
| 20 | Keps Nut 8-32 |
| 21 | Clip |
| 22 | Adjustment Screw-Air Shutter |
| 23 | Air Shutter |
| 24 | Screw 8-32 x 3/8`` |
| 27 | Screw 6-32x7/8`` |
| 28 | Eyelet |
