F9107W0 02 – MAIN TOP

Products

Position	Product
1	Screw 10-16×7/16“
2	Wire Raceway
3	Raceway Cover
4	Backguard Body
5	Left
5	Right
6	End Cap (Left)
6	End Cap (Right)
7	Screw
8	Thermostat
9	Selector Switch
10	Infinite Switch (Lt.Fr., Lt. Rr., Rt. Rr.)
11	Infinite Switch (Rt. Front)
12	Light-Indicator
13	Light-Indicator (Surface)
14	WPL 78565
15	Thermostat
16	Selector Knob
18	Infinite Knob
19	Lens-Indicator Light
20	Almond
20	White
21	Clock Bracket
22	Clock Knob
23	Clock Glass
24	Clock (60 Cycle)
24	Clock (50 Cycle)
25	Clock Motor
25	Clock Motor (50 Cycle (Optional))
