F9808B0 02 – CONTROL PANEL

Products

Position	Product
	xLens, Clock/Oven Control
1	SCREW
2	Raceway, Wire
3	Cover, Raceway
4	End Cap (Left)
4	End Cap (Right)
5	Support, Backguard (Right)
5	Support, Backguard (Left)
6	Clip, Backguard
7	WP308499 Whirlpool Nut
8	W10900107 Whirlpool Oven Surface Element Switch
10	Backguard
11	Spacer
12	Relay Circuit Board
13	Indicator Light, (Surface Unit)
14	Screw
15	WP4314961 Whirlpool Lite Switch
16	WP9750343 Whirlpool Light Lens
17	Knob, Infinite
18	Screw No.8-32×1/4“ (6 Req)
19	Screw
20	Knob, Clock
21	Panel, Control
22	Clock/Oven Control
23	Screw
24	Spacer, Infinite Control
25	Cover Plate
26	Bracket, Thermostat
27	Thermostat, Hob Element
28	Screw
