F9808L0 03 – COOKTOP

Products

Position	Product
1	WP3147132 Whirlpool Surface Element
2	WP3147131 Whirlpool Surface Element
3	Element, Thermal Lt Rear
4	Cooktop (White, W/Trim)
4	Cooktop (Almond, W/Trim)
4	Cooktop (Chrome)
5	Element Clamp, Large
6	Clamp
7	Clamp, Elmnt.
9	Nut, Mount. (2)
10	Screw
11	SCREW
12	Seal, Vent
13	Hinge-Main Cooktop (Right)
13	Hinge-Main Cooktop (Left)
14	Bottom, Burner Box
15	Screw No.8×5/8
16	Cover Plate
17	Support Plate
18	Baffle, Burner Box
19	Insulation
20	Extension, Vent Tube
21	WP308685 Whirlpool Microwave Screw
22	Brace, Element
23	Cross Brace
