FAK104Q1V1 03 – RECOMMENDED SPARE PARTS
Written by
in
FAK104Q1V1 03 – RECOMMENDED SPARE PARTS
Products
Position
Product
NI
WCI 5304455381
NI
Window Filler Kit,slider panel
1
WCI 5304455176
2
WCI 5304455177
3
WCI 5304455178
4
WCI 5304455179
5
WCI 5304455180
6
WCI 5304455181
6A
WCI 5304455380
7
WCI 5304455182
8
WCI 5304455183
9
WCI 5304455184
10
Adapter,scroll/front ,top
11
Bracket,evaporator ,left
12
Bracket,evaporator ,right
13
WCI 5304455188
14
WCI 5304455189
15
Control Box
16
WCI 5304455191
17
WCI 5304447350
18
WCI 5304447282
19
WCI 5304447369
20
WCI 5304455194
21
WCI 5304455199
22
WCI 5304455235
23
WCI 5304455236
24
WCI 5304447375
25
WCI 5304455202
26
WCI 5304455203
27
WCI 5304455204
28
WCI 5304455205
29
Compressor,with overload
30
WCI 5304455238
31
WCI 5304455208
32
Grille,plastic mesh ,rear
33
WCI 5304455210
34
WCI 5304455211
35
Bracket,condenser ,right
36
Bracket,condenser ,left
37
Shroud,fan housing
38
WCI 5304455215
39
Motor,fan
40
WCI 5304455217
41
Nut,hex flange ,1/4 in. (6 mm)
42
Brace,platform ,support
43
Bolt,platform ,adjustment
44
Platform,window mount
45
WCI 5304455222
46
WCI 5304455223
47
WCI 5304455224
48
WCI 5304455225
49
WCI 5304455226
50
Blower Wheel
51
Sensor,evaporator temp ,thermistor
52
WCI 5304455229
53
WCI 5304455230
54
WCI 5304455231
55
WCI 5304455376
56
WCI 5304455232
57
WCI 5304455233
58
WCI 5304455377
←
