FAK190GN0F 07 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*94947	5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
*94951	WCI G189379
*94949	WCI 3015098
*94952	WCI G189609
*94948	WIRING HARNESS-COMPR & LIGHTS
1	WCI G174734
2	WCI G174733
3	TUBE, INSULATION (2)
4	BRACKET-CONDENSER MOUNTING (4)
5	5308000039 Frigidaire Refrigerator Screw
6	WCI G188725
7	WCI G183584
8	CORD, SERVICE
9	WCI 3007173
10	WCI 3017762
12	5303006412 Frigidaire Refrigerator Cover Mounting Strap
13	5303271616 Frigidaire Refrigerator P1-Overload
14	5303305677 Frigidaire Replacement Filter Dryer Filters
15	COMPRESSOR WITH ELECTRICALS
16	CLIP (4)
17	218513300 Frigidaire Refrigerator Compressor Mount Grommet
18	WCI 08003633
19	WCI G188724
20	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
21	CAPACITOR-RUN
22	STRAP-CAPACITOR MTG
