FCD12TFA0 04 – SYSTEM AND AUTOMATIC DEFROST PARTS – Aparts

FCD12TFA0 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*18114	WCI 9960003
*18114	PAN RETAINER KIT-SERVICE
*18114	WCI 3200757
1	WCI 8016623
2	WCI 3200734
3	WCI 8009792
4	WCI 8016621
5	WCI 86512
6	WCI 8006983
7	SCREW-TOP MOUNTING (3)
8	WCI 8000997
9	BRACKET-CONDENSER MOUNTING (4)
10	WCI 8000027
11	CLAMP-CABLE (3)
12	WCI 8000064
13	WCI 69395961
14	WCI 8009596
15	CLIP (4)
16	WASHER (4)
17	WCI 8008778
18	WCI 3200716
19	WCI 3200718
20	WCI 8016583
21	WCI 8016584
22	DEFROST PAN-ORIGINAL
23	LOCK NUT-PAN MOUNTING
