FEB789CCBG 03 – BODY

FEB789CCBG 03 – BODY

Written by

in

FEB789CCBG 03 – BODY

Products

PositionProduct
*10738WCI 318078511
*10744WCI 3201881
*1074508002868 Frigidaire 0 Screw Assembly
*10739WCI 5304407813
*10748216858001 Frigidaire Refrigerator Screw
*10742SCREW, 8 X 5/8, SPARK MODULE
*107465303211311 Frigidaire Refrigerator Screw
*10737WCI 5303302745
*107475304464772 Frigidaire Refrigerator Wire Tie
*107433201861 Frigidaire Screw
*107415303323277 Frigidaire Oven Screw
*10740WCI 5303308447
1WCI 318066700
2WCI 318102000
2WCI 318071500
6Shelf,broiler pan
6WCI 318025202
6WCI 5303299719
9WCI 5303317977
10WCI 5303317976
12318394803 Frigidaire Oven Switch
14316116400 Frigidaire Oven Light Socket
15316538904 Frigidaire Oven Lamp Light
165304524341 Frigidaire Lens
17WCI 5304400195
37316217002 Frigidaire Oven Temperature Probe
41WCI 5303310526
54WCI 5303310514
56WCI 5303298951
58WCI 5303311218
58WCI 5303311219
59WCI 318072510
625304409888 Frigidaire Oven Terminal Block with Hardware
665303016247 Frigidaire Broil Element
67318255100 Frigidaire Oven Range Bake Element, 2300W
685304403015 Frigidaire Oven Support
70WCI 5303300142
71WCI 318071100
76WCI 318056104
80WCI 5303301261
81WCI 5303320846
82WCI 318071800
83WCI 318089519
86WCI 5303310524
88WCI 5303311222
89BWCI 318120702
89AWCI 5304404899
98WCI 318029901
98WCI 318029900
99WCI 318055420
101BRACKET-TRIM (NOT ILLUSTRATED)
102AWCI 318070700
102BWCI 318070701
103TRIM-BASE,SMALL ,BLACK
103WCI 318028700
107WCI 5303318711
108WCI 318073001
109FAN BLADE
111B316008401 Frigidaire Washer P-1
111A316136600 Frigidaire Oven Range Lock Nut
119318004900 Frigidaire Thermal Switch
124WCI 318076902
1255303311202 Frigidaire P1-Motor-Conv
127318317100 Frigidaire Adapter Assembly
128WCI 5303311163
1295303311164 Frigidaire Oven Spring
131WCI 318102202
132BEND-COVER, CONTROL HSG, LH
132AEND-COVER, CONTROL HSG, RH
150ABRACKET-SUPPORT, ACCESS COVER, LH
150BBRACKET-SUPPORT, ACCESS COVER, RH
185318531800 Frigidaire Oven Spacer
187WCI 318013501
188318531702 Frigidaire Oven Spacer
222PLATE, OVEN TEMP PROBE (NOT ILLUSTRATED)
263WCI 5303320346
