FEB789CCSG 03 – BODY

FEB789CCSG 03 – BODY

Written by

in

FEB789CCSG 03 – BODY

Products

PositionProduct
*10738WCI 318078511
*10737WCI 5303302745
*107475304464772 Frigidaire Refrigerator Wire Tie
*107465303211311 Frigidaire Refrigerator Screw
*10739WCI 5304407813
*10742SCREW, 8 X 5/8, SPARK MODULE
*1074508002868 Frigidaire 0 Screw Assembly
*10744WCI 3201881
*10740WCI 5303308447
*107433201861 Frigidaire Screw
*10748216858001 Frigidaire Refrigerator Screw
*107415303323277 Frigidaire Oven Screw
1WCI 318066700
2AWCI 318071500
2WCI 318102000
6BWCI 318025202
6WCI 5303299719
6AShelf,broiler pan
9WCI 5303317977
10WCI 5303317976
12318394803 Frigidaire Oven Switch
14316116400 Frigidaire Oven Light Socket
15316538904 Frigidaire Oven Lamp Light
165304524341 Frigidaire Lens
17WCI 5304400195
37316217002 Frigidaire Oven Temperature Probe
41WCI 5303310526
54WCI 5303310514
56WCI 5303302711
58WCI 5303311219
58WCI 5303311218
59WCI 318072510
625304409888 Frigidaire Oven Terminal Block with Hardware
665303016247 Frigidaire Broil Element
67318255100 Frigidaire Oven Range Bake Element, 2300W
685304403015 Frigidaire Oven Support
70WCI 5303300142
71WCI 318071100
76WCI 318056104
80WCI 5303301261
81WCI 5303320846
82WCI 318071800
83WCI 318089519
86WCI 5303310524
88WCI 5303311222
89AWCI 5304404899
89BWCI 318120702
98WCI 318029900
98WCI 318029901
99WCI 318055420
101WCI 318039512
102BWCI 318070701
102AWCI 318070700
103TRIM-BASE,SMALL ,WHITE
103WCI 318028701
107WCI 5303318711
108WCI 318073001
109FAN BLADE
111A316136600 Frigidaire Oven Range Lock Nut
111B316008401 Frigidaire Washer P-1
119318004900 Frigidaire Thermal Switch
124WCI 318076902
1255303311202 Frigidaire P1-Motor-Conv
127318317100 Frigidaire Adapter Assembly
128WCI 5303311163
1295303311164 Frigidaire Oven Spring
131WCI 318102202
132AEND-COVER, CONTROL HSG, RH
132BEND-COVER, CONTROL HSG, LH
150ABRACKET-SUPPORT, ACCESS COVER, LH
150BBRACKET-SUPPORT, ACCESS COVER, RH
185318531800 Frigidaire Oven Spacer
187WCI 318013501
188318531702 Frigidaire Oven Spacer
222PLATE, OVEN TEMP PROBE (NOT ILLUSTRATED)
263WCI 5303320346
