FEF322CASB 04 – COOKTOP AND DRAWER PARTS

FEF322CASB 04 – COOKTOP AND DRAWER PARTS

Written by

in

FEF322CASB 04 – COOKTOP AND DRAWER PARTS

Products

PositionProduct
*10840WCI 5303281584
1DRAWER-UTILITY
2SHIELD-PNL
4ASCREW, HEX WASHER HEAD, 8-18(AB) X 1/2 (NOT ILLUSTRATED)
4PANEL-BROILER, WHITE
73051163 Frigidaire Oven Range Rear Broiler Drawer Glide
15A318372211 Frigidaire Oven 6" Electric Range Burner Kit
155308011964 Frigidaire Surface Element P1
16316202388 Frigidaire Oven Maintop
17316057601 Frigidaire Oven Rod
18HINGE-MAIN TOP (RH)
18B131243700 Frigidaire Screw
18AHINGE-MAIN TOP (LH)
19316048413 Frigidaire Oven Range Chrome 8" Drip Bow
19AL304430992 Frigidaire 6" Drip Bowl Chrome FM
275303935058 Frigidaire Oven Burner Receptacle Kit
28A5303017715 Frigidaire Medallion
28MEDALLION, STAINLESS STEEL, SURF ELEM
39WCI 316026101
443131903 Frigidaire Door/Drawer Bumper
60WCI 5303288574
