| *80010 | SCREW, CR PAN HD SEMS, 8-32BP X 1.00 |
| *80009 | WCI 316071600 |
| *80004 | WCI 316001713 |
| *80002 | WIRING HARNESSES ARE NOT AVAILABLE FOR THIS MODEL |
| *80005 | LIGHT/LAMP, IND, HOT SURFACE |
| *80006 | LENS-LIGHT/LAMP, INDICATOR |
| *80007 | WCI 5303281584 |
| *80003 | 3203550 Frigidaire Oven Plug |
| *80008 | WCI 5309951550 |
| *80000 | 316021105 Frigidaire Oven Screw |
| *80011 | WCI 5303269859 |
| 1 | DRAWER-UTILITY |
| 1 | WCI 316075201 |
| 1 | WCI 316029410 |
| 2 | SHIELD-PNL |
| 2 | WCI 316015905 |
| 3 | WCI 316067802 |
| 3 | WCI 316081006 |
| 3 | WCI 316081007 |
| 4 | SCREW, HEX WASHER HEAD, 8-18(AB) X 1/2 (NOT ILLUSTRATED) |
| 4 | GLASS-OVEN DOOR, BLACK, OUTER |
| 4 | WCI 316056206 |
| 5D | NUT, T,TYPE, LEVELING SCREW (NOT ILLUSTRATED) |
| 5B | WCI 3934058 |
| 5A | SCREW-LEVELING |
| 5C | 316116000 Frigidaire Screw |
| 6 | 316067902 Frigidaire Oven Rack |
| 6 | SHIELD-INSULATION |
| 7 | WCI 316076401 |
| 7 | Hinge,oven door ,(2) |
| 7 | 3051163 Frigidaire Oven Range Rear Broiler Drawer Glide |
| 8 | PANEL-OVEN BOTTOM |
| 8 | WCI 316050303 |
| 9 | WCI 316066603 |
| 9 | WCI 316073800 |
| 10 | WCI 316073900 |
| 10 | SCREW-OVEN DOOR, WASHER HEAD, 10-24 X 1.81 |
| 11 | WCI 316061807 |
| 11 | WCI 5303015373 |
| 12 | THERMOSTAT, OVEN, NON SC |
| 12 | 5303202011 Frigidaire Door Seal |
| 13 | WCI 5303291407 |
| 13 | SWITCH-SELECTOR |
| 14 | 316022503 Frigidaire Light Lamp P-1 |
| 14 | 316116400 Frigidaire Oven Light Socket |
| 15 | WCI 316023110 |
| 15 | WCI 316023111 |
| 15A | 318198834 Frigidaire Oven Element |
| 15 | 316538904 Frigidaire Oven Lamp Light |
| 15 | WCI 5303305628 |
| 15 | 318178110 Frigidaire Oven Range 6" Surface Element |
| 15B | LIMITER SWITCH, LARGE/8 INCH (NOT ILLUSTRATED) |
| 16 | WCI 316035506 |
| 18 | HINGE-MAIN TOP (RH) |
| 18 | HINGE-MAIN TOP (LH) |
| 19 | WCI 316024406 |
| 20 | WCI 316045500 |
| 21 | SPACER-BODYSIDE, (8) |
| 23 | WCI 316033203 |
| 24 | 5304527841 Frigidaire Oven Rocker Switch (Black) |
| 27 | 5303284616 Frigidaire Range Bulb Clip Thermostat |
| 28 | Clip,wiring harness ,green ,main top |
| 28 | WCI 3131730 |
| 29 | 3051162 Frigidaire Oven Range Front Broiler Drawer Glide |
| 29 | WCI 5303271133 |
| 30 | BRACKET-HINGE, MAIN TOP, LH |
| 30 | BRACKET-HINGE, MAIN TOP RH |
| 31 | WCI 316054906 |
| 32 | WCI 316054900 |
| 36C | WCI 316041001 |
| 36B | WCI 316023301 |
| 36A | WCI 316033609 |
| 36 | WCI 316025100 |
| 39 | 5304529996 Frigidaire Handle Kit |
| 39 | WCI 316026100 |
| 40 | WCI 316025800 |
| 41 | WCI 3131570 |
| 44 | 3131903 Frigidaire Door/Drawer Bumper |
| 45 | WCI 316066101 |
| 46 | 318228310 Frigidaire Oven Lens |
| 54 | 5303935086 Frigidaire Oven Top Burner Switch Kit |
| 54 | 316436001 Frigidaire Oven Range Infinite Burner Switch |
| 57 | COVER-ACCESS |
| 58 | 316403803 Frigidaire Insulation |
| 58 | INSULATION, OVEN WRAPPER |
| 58 | INSUL - OVEN BACK (NON-ILLUSTRATED) |
| 59 | WCI 316073603 |
| 59 | BRACKET-MOUNTING,VENT TUBE |
| 59 | WCI 316023601 |
| 60 | WCI 5303288574 |
| 60 | COVER-OVEN FRONT |
| 62 | 5304409888 Frigidaire Oven Terminal Block with Hardware |
| 63 | PLATE-GROUND STRAP |
| 66 | 5303051140 Frigidaire Broil Element |
| 67 | 316075103 Frigidaire Oven Bake Element |
| 68 | 316203400 Frigidaire Oven Support |
| 71 | SHIELD, REAR WALL, REAR WALL |
| 82 | SHIELD, OVEN BOTTOM |
| 87 | WCI 5303206618 |
