FEP330YL0 03 – CONTROL PANEL

FEP330YL0 03 – CONTROL PANEL

Written by

in

FEP330YL0 03 – CONTROL PANEL

Products

PositionProduct
1End Cap L.H.
1Screw
1End Cap R.H.
2SHIELD (RH-White/Almond)
2SHIELD (LH-White/Almond)
10WP965173 Whirlpool Dishwasher Screw
10Timer, Clock Knobs Included
15Panel, Control
17WP3149404 Whirlpool Oven Surface Element Switch
17SWITCH-INF
18WP486579 Whirlpool Air Conditioner Screw
18Switch, Selector
19Thermostat, Oven
19WP313808 Whirlpool Screw
20Light, Indicator (250V)
21Light, Indicator (Includes No. 12) (Surface Unit On)
24WP3149983 Whirlpool Knob
25Knob, Temperature
26Clip, Tube
27Harness-Conduit Asm.
27SCREW
28Lens, Amber
31Knob, Selector
