FEP350VL0 06 – DOOR

Written by

FEP350VL0 06 – DOOR

Products

Position	Product
1	Lining
2	Window Assy
3	Insulation
4	Frame
5	Handle
6	Glass, Outer
7	Ring, Hold Down
8	Bracket “Z“ (8)
9	WP308685 Whirlpool Microwave Screw
10	Bumper, Rubber (2)
11	Bumper, Rubber (6)
13	Screw, Door Handle
