FFBD1821MW1B 02 – CONTROL PANEL/DOOR

FFBD1821MW1B 02 – CONTROL PANEL/DOOR

Written by

in

FFBD1821MW1B 02 – CONTROL PANEL/DOOR

Products

PositionProduct
46GASKET, VENT, TO DOOR LINER
47COVER, DOOR VENT
48COVER, CONTROL BOARD
49WCI 5304513719
505304483463 Frigidaire Dishwasher Switch
53WCI 5304512886
545304512887 Frigidaire Dishwasher Box
55WCI 5304483468
56WCI 5304513720
57WCI 5304483471
58FOAM ASSEMBLY, DOOR, INNER
59BOLT, DOOR SPRING, (2)
60SCREW, REC, M5 X 6, (5)
61WCI 5304483475
62HINGE ASSEMBLY, DOOR
63WCI 5304512889
64RING, CLAMPING, (2)
65WCI 5304512890
66PIN, HINGE JOINT, (2)
67WCI 5304512891
685304509267 Frigidaire Dishwasher Dispenser
69BRACKET, DISPENSER MTG., (2)
70SCREW, DISPENSER MTG., (6)
71GUARD, DOOR, WHITE, SIDE, (2)
72SCREW, REC TAP, ST3.5 X 13, (6)
73LINER ASSEMBLY, DOOR, INNER
75GASKET, VENT
77VENT ASSEMBLY, DOOR
