FFRE08C3Q11 03 – RECOMMENDED SPARE PARTSadmin2025-04-26T10:19:07+00:00FFRE08C3Q11 03 – RECOMMENDED SPARE PARTS
Products
| Position | Product |
|---|
| 1 | WCI 5304477067 |
| 2 | Panel,front grille ,tilt-out |
| 3 | Filter,air ,plastic frame |
| 4 | WCI 5304477068 |
| 5 | WCI 5304477050 |
| 6 | 5304477051 Frigidaire LOUVER |
| 7 | 5304477052 Frigidaire LOUVER |
| 8 | PC Board,display/input |
| 9 | Wire,connecting |
| 10 | Power Cord,electric ,LCDI |
| 11 | 5304501878 Frigidaire Remote Control |
| 12 | 5304495908 Frigidaire Cover Assembly |
| 13 | WCI 5304496240 |
| 15 | 5304504724 Frigidaire Sensor |
| 16 | Strap,capacitor clamp |
| 17 | 5304476066 Frigidaire Air Conditioner Capacitor |
| 18 | Ionizer,anion generator |
| 19 | WCI 5304495911 |
| 20 | Evaporator,with ,capillary tube |
| 21 | Tube,capillary |
| 22 | WCI 5304495940 |
| 23 | WCI 5304495941 |
| 24 | WCI 5304495942 |
| 25 | WCI 5304495943 |
| 26 | WCI 5304495944 |
| 27 | WCI 5304495926 |
| 28 | WCI 5304495927 |
| 29 | WCI 5304495928 |
| 30 | Blower Wheel,centrifugal fan |
| 31 | WCI 5304495945 |
| 32 | 5304483089 Frigidaire Blade Fan |
| 33 | Support,motor mount ,left |
| 34 | Support,motor mount ,right |
| 35 | Shroud,condenser/fan |
| 36 | WCI 5304496354 |
| 37 | WCI 5304495916 |
| 38 | Rail,shutter track ,top |
| 39 | Screw Kit,top rail mount |
| 40 | 5304495917 Frigidaire Air Conditioner Window Filler Kit |
| 41 | 5304491953 Frigidaire Air Conditioner Hardware |
| 42 | Seal kit,foam ,sash filler |
| 43 | 5304476201 Frigidaire Air Conditioner Filter Drier |
