FFU12K1DW1 07 – SYSTEM

Products

PositionProduct
15300123788 Frigidaire Refrigerator Condenser
35304509722 Frigidaire Refrigerator Shelf
45303305677 Frigidaire Replacement Filter Dryer Filters
5WCI 216943100
6297001600 Frigidaire Shelf Support
7297001500 Frigidaire Shelf Support
11SUPPORT-REAR SHELF
12GROMMET-SPACER
13WCI 216138900
27216498900 Frigidaire Refrigerator Grommet
295304507765 Frigidaire Refrigerator Compressor Kit
305304493950 Frigidaire Start Relay Kit
31216954208 Frigidaire Refrigerator Controller
34SLEEVE-COMPRESSOR
35SCREW, LND HEX SEMS, 1/4-28 UNFX, COMPRESSOR
36WCI 216940100
43A297315800 Frigidaire Refrigerator Clip
53WCI 216347800
86216036601 Frigidaire Refrigerator Screw
