FGC3X4XAB1 03 – BURNER PARTS

FGC3X4XAB1 03 – BURNER PARTS

Written by

in

FGC3X4XAB1 03 – BURNER PARTS

Products

PositionProduct
*79637SWITCH-IGNITOR
*79637WCI 5303210992
*79637HARNESS-HV GROUND
*79637WIRE-IGNITOR (36 INCH)
*79637WIRE-IGNITOR (30 INCH)
*79637WIRE-IGNITOR (20 INCH)
*79637WIRE-IGNITOR (14 INCH)
*79637HARNESS-IGNITION
*79637316069301 Frigidaire Oven Burner Mounting Primary Screw
1WCI 5303284581
25308007974 Frigidaire Pressure Regulator
3VALVE-TOP BURNER, SMALL, W/SCREW(3)
5WCI 5303209020
6WCI 5303209021
7WCI 316010600
9SEAL BURNER (2) MED
11WCI 5303209024
12WCI 5303209025
13WCI 5303283686
155304505695 Frigidaire Oven Module
16WCI 316010700
17316011200 Frigidaire Oven Top Burner Igniter
19ORIFICE-TOP BURNER, (4)
