FGP345VL1 08 – OVEN DOOR, LIT/OPTIONALadmin2025-04-26T08:40:47+00:00FGP345VL1 08 – OVEN DOOR, LIT/OPTIONAL
Products
| Position | Product |
|---|
| List, Repair Parts |
| Guide, Use & Care |
| Instructions, Installation |
| 1 | Window |
| 2 | Glass |
| 3 | Panel, Door (Almond) |
| 3 | Panel, Door (White) |
| 4 | Handle |
| 5 | Screw, Door Handle |
| 5 | Spacer (4) |
| 7 | Insulation |
| 8 | Liner, Door |
| 9 | WP308685 Whirlpool Microwave Screw |
| 9 | Ring, Hold Down |
| 15 | Clip, Bottom (2) |
| 16 | Clip, Side (2) |
| 17 | Clip, Top |
