FGP355VL0 02 – MANIFOLD

Products

Position	Product
1	Support, Burner
2	Ignitor (L.H.)
2	Ignitor (R.H.)
3	Bracket, Spark Ignitor (2)
3	Screw
4	Burner, Rear (2)
5	Burner, Front (2)
6	Screw, Mounting
6	Pipe, Manifold
7	Thermostat
8	WP4157180 Whirlpool Surface Burner Ignition Switch
9	Valve, 90~ (4) (Includes Ill. No. 33)
10	Regulator, Pressure
11	Tubing 3/8“
12	WP308685 Whirlpool Microwave Screw
12	Valve, Safety
13	Burner, Oven
14	Spreader, Flame
15	Valve, Shut Off
18	Pilot
19	Bracket, Ignitor
21	Support, Manifold (R.H.)
22	Support, Manifold (L.H.)
23	Plate, Spark Module
23	Module, Spark
