FGP355VL0 03 – EXTERNAL OVEN
Written by
in
FGP355VL0 03 – EXTERNAL OVEN
Products
Position
Product
1
Panel, Side (2) (Almond)
1
Panel, Side (2) (White)
2
Frame, Front
3
Rail, Base (2)
4
Base, Front
4
Screw, 10-12 X 1/2 (4)
5
Support, Main (2)
5
Screw, 10-32 X 1/2 (1)
6
Support, Rear (2)
8
Flue, Box
8
SCREW
9
Panel, Rear
10
Burner Box
10
WP308685 Whirlpool Microwave Screw
12
Screw, 10-24 X 3/8 (2)
12
Hinge, Door (2)
13
Seal, Door (2)
15
Locator stud (2)
20
Stud Screw (2)
20
Shield, Insulation
21
Leg, Leveler (4)
22
Nut (4)
23
Extension Burner Box
26
Cover, Wire
31
Anti Tip Kit
32
Anchor (2)
33
Bracket
34
Screw
←
