FGP357YL1 03 – COOKTOP

Products

PositionProduct
1Grate
2Top, Main (White)
2Top, Main (Almond)
3Bracket, Hinge LH
4Bracket, Hinge RH
5Panel, Manifold
6Knob, Control (4)
7Cap, Burner (4)
8Ring, Trim
9Screw, Burner Mtg.
10Knob, Thermostat
11Thermostat
12Bracket, Mounting (L.H.)
12Bracket, Mounting (R.H.)
